99-9305
DASH DISASSEMBLY
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip and remove the hazard/door
lock switch.
(Figure A)
2
BMW X3 2004-2010
(NON-NAV MODELS)
Unclip and remove the a/c vents
above the radio.
( Figure B)
3
Remove (2) Phillips screws on top of
the radio/climate control panel fac-
ing down.
(Figure C)
4
Unclip and remove the radio/climate
control panel.
(Figure D)
5
Remove (2) Phillips screws securing
the radio.
(Figure D)
6
A
B
C
D
1
To Next Page
