Metra Electronics 99-9305 - Kit Assembly and Installation; Bracket Attachment to Radio; Radio;Bracket Assembly Mounting; Radio Housing Securing

2
Secure the corresponding bracket to
the aftermarket radio using the
hardware supplied with the radio.
(Figure A)
1
Using a drill screw the radio/bracket
assembly into the dash using the
supplied (4) Phillips screws.
(Figure B)
2
Position the radio housing over the
radio face and secure using the fac-
tory hardware.
(Figure C)
3
NOTE:
If the ISO screws supplied with
the aftermarket radio are too big, use
the supplied (4) Phillips ISO screws.
ISO DIN HEAD UNIT PROVISION
99-9305
KIT ASSEMBLY
A
B
C
