DP-3002B
Kit Assembly
ISO DDIN radio provision
1. Install the (11) included panel clips
to the radio trim panel. The factory
panel clips may be used if desired.
2. Attach the radio brackets to the
radio and secure using the screws
supplied with the radio and slide
into dash opening. (Figure A)
3. Snap the radio trim panel over the
radio until it clicks in.
4. Locate the factory wiring harness
in the dash. Metra recommends
using the proper mating adapter
from Metra or AXXESS. Test the
radio for proper operation.
5. Reassemble the dash in reverse
order of disassembly.
3
(Figure A)
