Alimentations stabilisées 3
AX 501
LEGENDE
1
Interrupteur Marche / Arrêt
6
Potentiomètre réglage tension « fin »
2
Borne de sortie (+)
7
Potentiomètre réglage courant
3
Borne de sortie (-)
8
Voyant de courant limite « LIMIT »
4
Borne de terre
9
Affichage de la tension
5
Potentiomètre réglage tension « gros »
10
Affichage du courant
LEGEND
1
On / Off switch
6
"Fine" voltage adjustment potentiometer
2
Output terminal (+)
7
Current adjustment potentiometer
3
Output terminal (-)
8
« LIMIT » current LED
4
Earth terminal
9
Voltage display
5
"Coarse" voltage adjustment potentiometer
10
Current display
BESCHREIBUNG
1
Ein- / Aus-Schalter
6
Potentiometer Spannungseinstellung fein
2
Ausgangsbuchse (+)
7
Potentiometer Stromeinstellung
3
Ausgangsbuchse (-)
8
Kontrollleuchte für maximalen Strom
4
Erdungsanschluss
9
Spannungsanzeige
5
Potentiometer Spannungseinstellung grob
10
Stromanzeige
LEGENDA
1
Interruttore ON/OFF
6
Potenziometro di regolazione tensione “fine”
2
Boccola d’uscita (+)
7
Potenziometro di regolazione corrente
3
Boccola d’uscita (-)
8
Spia di corrente “LIMIT”
4
Boccola di terra
9
Visualizzazione della tensione
5
Potenziometro di regolazione tensione
“approssimativa”
10
Visualizzazione della corrente
LEYENDA
1
Interruptor Funcionamiento / Parada
6
Potenciómetro ajuste tensión “fino”
2
Borne de salida (+)
7
Potenciómetro ajuste corriente
3
Borne de salida (-)
8
Indicador luminoso corriente límite
4
Borne de tierra
9
Visualización de la tensión
5
Potenciómetro ajuste tensión “grueso”
10
Visualización de la corriente
