TECHNICAL SPECIFICATIONS
Model
208AP
210AP
212AP
215AP
Power supply:
100
-
240 V AC, 50/60 Hz
100
-
240 V AC, 50
/60 Hz
100
-
240 V AC, 50/60 Hz
100
-
240 V AC, 50/60 Hz
Rated power:
80 W RMS
90 W RMS
140 W RMS
150 W RMS
Program power:
160 W
180 W
280 W
300 W
LF speaker:
20 cm w
oofer (10") with
40 mm voice coil
25 cm
w
oofer (12") with
40 mm voice coil
30 cm
w
oofer (1
2") with
40 mm voice coil
38 cm
w
oofer (15") with
50 mm voice coil
HF speaker:
25 mm compression
driver (1")
25 mm compression
driver (1")
25 mm compression
driver (1")
25 mm compression
driver (1")
Storage media:
USB devices and
SD(HC) cards
USB
devices and
SD(HC) cards
USB devices and
SD(HC) cards
USB devices and
SD(HC) cards
File system
:
FAT32
FAT32
FAT32
FAT32
Playback format:
MP3, WAV
MP3, WAV
MP3, WAV
MP3, WAV
Number of files
:
max. 999
max. 999
max. 999
max. 999
Inputs:
Mic:
combination XLR
/
6.3 mm jack
combination XLR/
6.3 mm jack
3
-
pin XLR or
6.3 mm jack
3
-
pin XLR or
6.3 mm jack
Line:
stereo RCA
stereo RCA
stereo RCA
stereo RCA
Outputs:
Line:
stereo RCA
stereo RCA
stereo RCA
stereo RCA
Max. SPL:
111 dB (1 m)
115 dB (1 m)
120
dB (1 m)
122 dB (1 m)
Frequency range:
75 Hz
-
20 kHz
45 Hz
-
20 kHz
50 Hz
-
20 kHz
45 Hz
-
20 kHz
Dimensions (HxWxD):
438 x 295 x 245 mm
545 x 360 x 295 mm
630 x 420 x 342 mm
740 x 480 x 395 mm
Weight:
5.5 kg
7 kg
10 kg
15 kg
Model
208A
210A
212A
215A
Power supply:
100
-
240 V AC, 50/60 Hz
100
-
240 V AC, 50/60 Hz
100
-
240 V AC, 50/60 Hz
100
-
240 V AC, 50/60 Hz
Rated power:
80 W RMS
90 W RMS
140 W RMS
150 W RMS
Program power:
160 W
180 W
280 W
300 W
LF speaker:
20 cm
w
oofer (8") with
40 mm voice coil
25 cm
w
oofer (10") with
40 mm voice coil
30 cm
w
oofer (12") with
40 mm voice coil
38 cm
w
oofer (15") with
50 mm voice coil
HF speaker:
25 mm compression
driver (1")
25 mm compression
driver (1")
25 mm compression
driver (1")
25 mm compression
driver (1")
Inputs:
Mic:
combination XLR/
6.3 mm jack
combination XLR/
6.3 mm jack
3
-
pin XLR or
6.3 mm jack
3
-
pin XLR or
6.3 mm jack
Line:
stereo RCA
stereo RCA
stereo RCA
stereo RCA
Outputs:
Line:
stereo RCA
stereo R
CA
stereo RCA
stereo RCA
Max. SPL:
111 dB (1 m)
115 dB (1 m)
120 dB (1 m)
122 dB (1 m)
Frequency range:
75 Hz
-
20 kHz
65 Hz
-
20 kHz
50 Hz
-
20 kHz
45 Hz
-
20 kHz
Dimensions (HxWxD):
438 x 295 x 245 mm
545 x 360 x 295 mm
630 x 420 x 342 mm
740 x 480
x 395 mm
Weight:
5.5 kg
7 kg
10 kg
15 kg
www.metroaudiosystems.de
27
MODEL ES-8A ES-10A ES-12A ES-15A
Power supply 100-240 V AC, 50/60 Hz 100-240 V AC, 50/60 Hz 100-240 V AC, 50/60 Hz 100-240 V AC, 50/60 Hz
Rated power 60 W RMS 80 W RMS 150 W RMS 200 W RMS
Program power / Peak 120 W / 240 W 160 W / 320 W 300 W / 600 W 400 W / 800 W
Amplication Class AB Class AB Class AB Class AB
LF driver 8’’ woofer with 10’’ woofer with 12’’ woofer with 15’’ woofer with
1,18’’ voice coil 1,5’’ voice coil 1,5’’ voice coil 2’’ voice coil
HF driver 1’’ exit -1’’ 1’’ exit -1’’ 1’’ exit -1’’ 1’’ exit -1’’
compression driver compression driver compression driver compression driver
Dispersion 90
o
x 50
o
90
o
x 50
o
90
o
x 50
o
90
o
x 50
o
Storage media USB devices and USB devices and USB devices and USB devices and
SD(HC) cards SD(HC) cards SD(HC) cards SD(HC) cards
File system FAT32 FAT32 FAT32 FAT32
Playbackformat MP3, WAV MP3, WAV MP3, WAV MP3, WAV
Numberofles max. 999 max. 999 max. 999 max. 999
INPUTS
Mic combination XLR combination XLR// 3-pin XLR or 3-pin XLR or
6.3 mm jack 6.3 mm jack 6.3 mm jack 6.3 mm jack
Line stereo RCA stereo RCA stereo RCA stereo RCA
OUTPUTS
Line stereo RCA stereo RCA stereo RCA stereo RCA
Max. SPL (Peak) 107 dB (1 m) 111 dB (1 m) 114 dB (1 m) 116 dB (1 m)
Frequencyrange 90 Hz - 18 kHz 80 Hz - 18 kHz 65 Hz - 19 kHz 55 Hz - 18 kHz
Dimensions(HxWxD) 433 x 295 x 245 mm 550 x 360 x 295 mm 640 x 420 x 342 mm 740 x 480 x 395 mm
Weight 5,14 kg 7,8 kg 11,5 kg 16,06 kg

Metro DataVac ES ACTIVE Series Specifications

General

Brand	Metro DataVac
Model	ES ACTIVE Series
Category	Speaker System
Language	English
