3
Metro Pedestal Fires
To minimise freight damage, the pedestal base has been
packaged inside the rebox. Please note: you should only
assemble this wood re if you are suitably experienced in
wood re assembly and installation.
To safely assemble your Metro, please proceed as follows: -
- Safely remove straps by cutting straps with scissors.
- Lift off carton, turn upside down (use to hold all discarded
packaging).
- Lift off the top grill and place somewhere safe. Be careful
not to chip the enamel coating.
- Open the door 90 degrees and lift the door off the hinge
and place somewhere safe. Be careful not to chip the
enamel coating.
- Remove the pedestal packed in a cardboard wrap
- Remove the pedestal mount plate
- Remove pedestal heat shield
Note: For some models this may be taped to rear heat shield and
the ECO Tiny Ped is already assembled.
- Remove the side bricks, door handle and the bolt bag
- Remove the 2 tek screws at the base of the inside of the
rebox that x the wood re to the pallet.
- It is recommended that 2 people work together with this
step. Grab the underneath top of the rebox door opening
with one hand, holding the ue spigot with the other, slowly
lift the front of the wood re all the way back and rest the
wood re on its rear heat shield on the oor. Remove the
packaging pallet.
- Fit the pedestal heat shield over the 4 bolts as shown in
Diagram 1, with the open edge facing the front of the
Metro (up)
- Position the pedestal with its front facing over the 4 bolts
and t the washers and nuts supplied, check to ensure the
pedestal is correctly aligned and securely tighten the nuts
- It is recommended that 2 people work together with this
step. Grab the ue spigot with one hand and the other
hand underneath the top of the rebox door opening, lift
upwards standing the wood re onto its pedestal.
- Re-t the door and top grill
- Open the door fully and t the side bricks to each side of
the re box. Location lugs are tted to the base and rear
of the rebox to retain the side bricks in position. Refer to
Diagram 2.
Note: The ECO Tiny Ped model utilises a slightly different pedestal to
that detailed in Diagram 1. The rear panel on the pedestal must be
turned around with the return fold facing back the opposite way. This
creates the mounting plate.
All Metro Models
Check to ensure the top bafe is in its correct position in the
top chamber of the rebox. It should be resting on four support
lugs (two on each side of the rebox). The bafe must be
hard back against the rear of the rebox with the “promet
extension” (white board) or return front steel edge of the bafe
facing forward as illustrated in Diagram 2.
Assembling your Metro wood re
Cook top grill
Door
Handle
Pedestal
Pedestal
heat shield
Pedestal
mounting plate
(not available
on tiny ped)
Diagram 1
(For Ped &
Base models)
Top baffle
Diagram 2
Side brick
