Minimum clearances
All Metro wood res comply with AS/NZS2918:2001. Minimum
clearances shown below are detailed in millimetres,
with a Pioneer double ue shield tted to the appliance .
Measurements are taken from the following reference points
as illustrated:
- From the nearest combustible wall or surface
(A, B, D, E, G, H)
- From the Metro’s ue centre (A, B, C, D)
- From the Metro’s cabinet/heatshield outermost point
(E, F, G, H)
- To the edge of the ash oor protectors non-combustible
surface (C, F, I, J, K, L, M)
AS/NZS2918:2001 allows for a reduction in minimum clearances
as detailed in Section 3, tables 3.1 and 3.2 of the standard.
Some Metro models have undergone additional testing which
allows for reduced clearances. Please see the footnotes
below the tables for applicable models.
Specications were correct at the time of printing, but may
alter and those detailed within should be used only as a
guide. If in doubt, please consult your Metro retailer.
Wetback connections
Connections below are taken facing the Metro/wall.
• Tiny Series models are 92mm left of the ue centre.
• Wee Series models are 226mm left of the ue centre.
• The Classic Rad is 183mm left of the ue centre.
• Xtreme Series models are 275mm left of the ue centre.
• All other models are 140mm left of the ue centre.
Clearance chart
N
O
Metro clearances and specications (Minimum clearances shown are in mm, with a Pioneer double ue shield tted)
Minimum installation clearances with a Pioneer double flueshield fitted (mm) Wetback Dimensions
Clean Air Models A B C D E F G H I J K L M N O
Width Depth Height
ECO Tiny Ped 210 430 580 290 25 200 185 60 790 650 990 875 250 280 470 490 530 665
ECO Tiny Rad
225 552 580 420 150 200 300 75 805 650 1165 925 250 280 470 505 530 665
R1 243 774 586 554 280 244 530 100 829 825 1370 1118 425 N/A N/A 488 485 668
R2
246 858 626 582 275 235 570 100 872 905 1449 1203 505 N/A N/A 575 537 690
Wee Rad
1
251 568 577 455 150 230 260 100 828 825 1224 1015 425 295 485 615 498 688
Wee Rad Base
271 678 577 489 180 230 370 120 848 825 1270 1049 425 295 485 615 498 691
Wee Ped
2
263 651 580 490 170 230 350 110 843 825 1274 1050 425 295 485 602 503 665
Classic Rad
3
257 695 780 500 220 229 430 100 1037 728 1487 1168 328 393 583 530 707 680
Xtreme Ped 251 624 630 441 110 227 280 100 881 907 1254 1065 507 349 539 688 554 721
Xtreme Rad
251 650 630 458 100 227 280 100 881 907 1277 1077 507 349 539 740 554 743
Xtreme Rad Base 251 650 630 458 100 227 280 100 881 907 1277 1077 507 349 539 740 554 743
ECO Euro Rad DV
250 625 625 435 80 200 250 100 875 905 1240 1065 505 338 528 750 575 745
ECO Euro Ped DV
4
230 585 625 495 170 200 250 80 855 905 1325 1120 505 325 515 670 575 715
Mega Rad
285 720 728 497 100 224 300 130 1013 1006 1431 1227 606 300 490 840 657 749
1
Wee Rad corner clearance (E) can be reduced to 120mm with the Wee Rad corner wing shields fitted. This in turn also reduces clearances (D) to
425mm, (K) to 1180mm and (L) to 985mm. When fitting the corner wing shields the Wee Rad itself must be installed to a corner clearance (E) of 120mm.
The corner wing shields are then fitted which gives a wall to shield corner clearance of 100mm.
2
Wee Ped corner clearance (E) can be reduced to 115mm if installed with a Pioneer double flue shield with the side extensions fitted. This in turn also
reduces clearances (D) to 436mm, (K) to 1197mm and (L) to 996mm.
3
Classic Rad corner clearance (E) can be reduced to 180mm if installed with a Pioneer double flue shield with the side extensions fitted. This in turn also
reduces clearances (D) to 460mm, (K) to 1430mm and (L) to 1127mm.
4
ECO Euro Ped corner clearance (E) can be reduced to 110mm if installed with a Pioneer double flue shield with the side extensions fitted. This in turn also
reduces clearances (D) to 435mm, (K) to 1240mm and (L) to 1060mm.
