1. SPECIFICATIONS
MAINS SUPPLY REQUIREMENTS:
Voltage 110 - 120 Volts AC or
220 - 240 Volts AC
Frequency 50/60 Hz
Power 75VA Maximum
FUSES:
Primary external 2 of 1A 5 X 20 mm DA205
Internal Fuse 1 of 4A 5x20mm DA205
POWER SUPPLY:
Integrated switchmode power supply complying with IEC 601-1: 1988 and
amendments.
Secondary Voltages 24 Volts DC @ 2.7A
ULTRASOUND OUTPUT - 1 MHz:
Frequency 1.1 MHz +/- 10%
Output Intensity, Continuous Mode 3.0 Watts/cm
2
+/- 20% Maximum
Power/Intensity Display Accurate to +/- 20% of reading for
outputs in excess of 0.2 Watts/cm
2
.
Effective Radiating Area 5.0 square cms +/- 20%.
ULTRASOUND OUTPUT - 3 MHz:
Frequency 3.3 MHz +/- 10%
Output power in continuous mode 3.0 Watts/cm
2
+/- 10% maximum
(Equivalent to 2.4 watts absolute for the
1cm head)
1.6 Watts/cm
2
+/- 10% maximum
(Equivalent to 8.0 watts absolute for the
2.5 cm head)
Metron Accusonic Plus
__________________________________________________________________
Version 1.6 March 2002 Page 1 of 12
