Page 30
CLUTCH CABLE AND RELATED PARTS
KEY PART NO. QTY
125
QTY.
160
QTY
225
DESCRIPTION
1 E01932 2 2 2 Thimble, Cable w/Bolt, Nuts & Washers
2 E01933 1 1 1 Clamp, Cable - Bolt Type
3 E01934 1 0 0 Cable, Clutch - 12’3"
E01935 0 1 0 Cable, Clutch - 14’3"
E01936 0 0 1 Cable, Clutch - 16’3"
4 E01647 1 1 1 Eye Bolt
5 E01938-99 1 1 1 Lever
6 E01939 1 1 1 Locking Rod
7 E01639 1 1 1 U-Bolt
8 E01648 1 1 1 Insulator
9 E01942 1 1 1 Cotter Pin, 3/16x1-1/4"
10 E01642-99 1 1 1 Spring, Compression C0720-085-2750-M
11 E01945 1 1 1 Locking Rod Plate w/2-1/4x3/4" Machine Bolts & Nuts
12 E01646 1 1 1 Lever Pivot Bolt, 1/2x1-1/4 w/Lock Nut
13 E01936-99 1 1 1 Guide, Cable Pulley
14 E01645 1 1 1 Clamp, Cable - Crimped Type
17 E01941-99 1 1 1 Bolt 1/2 x 2” Machine 3-1/2” Flat Washer & 2-1/2” Nuts
18 E01847 1 1 1 125-390 Pulley Arm Brkt.
