LEOPARD OPERATING INSTRUCTIONS
41
LEOPARD DIMENSIONS
NOTE: For dimensions and weight for the MG-LEOPARD top grid and MCF-LEOPARD caster frame, refer to the
MG-LEOPARD/900 Assembly Guide (PN 05.243.080.01) available at www.meyersound.com
.
24.56 in
[624 mm]
10.08 in
[256 mm]
19.66 in
[499 mm]
21.66 in
[550 mm]
26.93 in
[684 mm]
11.11 in
[282 mm]
5.60 in
[142 mm]
