MTS-4 Array Coverage and Maximum SPL
Number of Horizontal
MTS-4s @ Angle
1 2 @ 15° 2 @ 30° 2 @ 45° 3 @ 15° 3 @ 30° 3 @ 45°
Coverage Max Peak Coverage Max Peak Coverage Max Peak Coverage Max Peak Coverage Max Peak Coverage Max Peak Coverage Max Peak
H V dB SPL H V dB SPL H V dB SPL H V dB SPL H V dB SPL H V dB SPL H V dB SPL
Vertical Rows of MTS-4s
@ Angle
1 70° 60° 140 50° 60° 146 60° 60° 145 100° 60° 142 80° 60° 149 120° 60° 147 150° 60° 145
2 @ 0° (LT) 70° 30° 146 50° 30° 152 60° 30° 151 100° 30° 148 80° 30° 155 120° 30° 153 150° 30° 151
2 @ 15° 70° 50° 145 50° 50° 151 60° 50° 150 100° 50° 147 80° 50° 154 120° 50° 152 150° 50° 150
2 @ 30° 70° 90° 143 50° 90° 149 60° 90° 148 100° 90° 145 80° 90° 152 120° 90° 150 150° 90° 148
Number of Horizontal
MTS-4s @ Angle
4 @ 15° 4 @ 30° 4 @ 45° 5 @ 15° 5 @ 30° 5 @ 45°
Coverage Max Peak Coverage Max Peak Coverage Max Peak Coverage Max Peak Coverage Max Peak Coverage Max Peak
H V dB SPL H V dB SPL H V dB SPL H V dB SPL H V dB SPL H V dB SPL
Vertical Rows of MTS-4s
@ Angle
1 100° 60° 151 140° 60° 148 190 60° 146 110° 60° 153 180° 60° 148 240 60° 146
2 @ 0° (LT) 100° 30° 157 140° 30° 154 190 30° 152 110° 30° 159 180° 30° 154 240 30° 152
2 @ 15° 100° 50° 156 140° 50° 153 190 50° 151 110° 50° 158 180° 50° 153 240 50° 151
2 @ 30° 100° 90° 154 140° 90° 151 190 90° 149 110° 90° 156 180° 90° 151 240 90° 149
