Meyer Sound MTS-4 User Manual

2
According to ISO/IEC Guide and EN 45014
The product herewith complies with the require-
ments of the Low Voltage Directive 73/23/EEC and
the EMC Directive 89/336/EEC.
declares that the product:The Manufacturer:
Product Name: MTS-4
Product Options: All
Name: Meyer Sound Laboratories
Address: 2832 San Pablo Avenue
Berkeley, California 94702-2204, USA
conforms to the following Product Specifications:
Safety: EN 60065: 1994
EMC: EN 55022: 1987 - Class A
IEC 801-2: 1984 - 8 kV
IEC 801-3: 1984 - 3 V/m
IEC 801-4: 1984 - 0.5 kV Signal Lines,
Meyer Sound Laboratories, Inc.
2832 San Pablo Avenue
Berkeley, California 94702
Telephone:510 - 486 - 1166
FAX: 510 - 486 - 8356
E-mail: techsupport@meyersound.com
http://www.meyersound.com
Made by Meyer Sound, Berkeley, CA, USA
European Office:
Meyer Sound Germany
GmbH
Carl Zeiss Strasse 13
56751 Polch, Germany
UU
LL
CC
UU
LL
®®
LISTED
3K59
COMMERCIAL
AUDIO SYSTEM
Meyer Sound Germany
Gmbh
Carl Zeiss Strasse 13
56751 Polch, Germany
Telephone: 49.2654.9600.58
FAX: 49.2654.9600.59
Declaration of Conformity
Contact Information
Office of Quality Manager
Berkeley, California USA
October 1, 1995
1.0 kV Power Lines
Shock: 30 g 11 msec half-sine
on each of 6 sides
Vibration: 10 – 55 Hz (0.010 m
peak-to-peak excursion)
Operating temperature:0° C to +45° C
Nonoperating temp: < –40° C or > +75° C
Humidity: to 95% at 35°C
Operating altitude: to 4600 m (15,000 ft)
Nonoperating altitude: to 6300 m (25,000 ft)
Environmental Specifications for
Meyer Sound Electronics Products
!
Pour indiquer les risques
résultant de tensions
dangereuses
Zu die gefahren von
gefährliche spanning zeigen
Important operating
instructions
Pour indequer important
instructions
Frame or chassis
Masse, châssis
Rahmen oder chassis
Protective earth ground
Terre de protection
Die schutzerde
Para indicar azares provengo
de peligroso voltajes
Para indicar importante
funcionar y mantenimiento
instrucciones
Armadura o chassis Tierra proteccionista
These symbols indicate important safety or operating features in this booklet and on the chassis.
Dangerous voltages:
risk of electric shock
Symbols Used
Zu wichtige betriebs-
anweisung und unter-
haltsanweisung zeigen

Meyer Sound MTS-4 Specifications

Acoustical

frequency response	30 Hz – 16 kHz
maximum peak SPL	140 dB
dynamic range	> 110 dB

Transducers

sub frequency	18” diameter
low frequency	15” diameter
middle frequency	12” diameter

Amplifiers

type	Complementary power MOSFET output stages class AB/H
burst capability	2480 Watts (620 Watts/channel)
THD, IM, TIM	< .02 %

Audio Input

type	10 kΩ impedance, electronically balanced
connector	XLR (A-3) male and female
nominal input level	+4 dBu (1.23 Vrms)

AC Power

automatic voltage selection	85 – 134 V / 165 – 264 V; 50 Hz / 60 Hz
max continuous RMS current	115 V: 14 A 230 V: 7 A 100 V: 16 A
max burst RMS current	115 V: 26 A 230 V: 13 A 100 V: 30 A

Physical

dimensions	21.25” W x 56.75” H x 30” D
weight	280 lb (127 kg)
rigging working load	600 lb
