INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
button. The red LED will begin to flash for 15 seconds. Take the Transmitter
while the red LED is flashing and firmly depress the ON button within the 15
seconds. Now the unique address of the Transmitter will only be recognized by
that matched receiver. The red LED will automatically shut off after 15 seconds.
To make sure the programming procedure was successful, depress any of the
Transmitter buttons and the red LED in the receiver should light. Re-install the
cover noting drain hole position and re-connect the PWM (green wire) to the
Specifications:
• Up to180 amp output for up to 5 seconds.
• Continuous output of up to 80 amps.
• 5 motor speed outputs of approximately 1/5,2/5,3/5,4/5 and 5/5ths of
motor current draw.
• Built in E-Stop using OFF button.
• Built-in over current safety protection. If a lock-up condition occurs at the
motor causing the motor to draw more than 200 amps the unit will
automatically shut down and must be turned back on using the ON button
after the circuit temperature drops to an acceptable range taking 1 to 30
seconds. Warning: If this situation continues to re-occur the operator
needs to check for reasons why the motors will not turn.
motor. The
Variable speed controller is now ready to operate the DC motor.
