INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
ITEM PART NUMBER DESCRIPTION QTY
29 62690 NUT, 1/4” SER FLANGE 5
28 62189 BOLT, 1/4” X 3/4” HH 4
27 64415 RETAINER, CLUTCH 1
26 62268 COVER, CLUTCH 1
25 62752 BOLT, 5/16 X 3/4 HH 1
24 62944 WIRE, REM. BATT. NEGATIVE 1
23 64086 CABLE, SPREADER CONTROL 1
22 62940 V-BELT, BX-46 1
21 64416 FORM, CONVEYOR FLOOR 1
20 62106 BOOT, ALT CABLE 2
19 62640 BOLT, 5/16 X 3/4 CA 18
18 64244 WELD, DRAG CHAIN 1
17 62743 NUT, 3/8” SER FLANGE 8
16 62695 BOLT, 3/8” X 1 1/4” HH 7
15 63565 FLATWASHER, 3/8” 4
14 62638 LOCKNUT, 3/8” VINYL 3
13 63264 FORM, GUARD, CONVEYOR 1
12 62772 LOCKWASHER, 1/2” 4
11 62750 BOLT, 1/2” X 3/4” HH 4
10 63117 SUB- Y, GEARBOX 1
9 62336 NUT, 1/2” HEX JAM 4
8 62304 WELD, TAKEUP BOLT 2
6 62641 NUT, 5/16 SER FLANGE SS 18
5 64418 CONNECTOR, BUTT 2
4 64419 WIRE, BROWN JUMPER 4” 1
3 64064 CAP, IDLER 2
2 62007 DECAL, CAUTION 1
1 64420 WELD, HOPPER 16GA S2 1
BASE LINE PV SERIES
7 64417 PV SHIPPING CARTON 1
