PV SERIES
INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
ITEM PART NUMBER DESCRIPTION QTY
91 63310 NUT, 5/16” SER FLANGE 7
90 63305 BOLT, 5/16” X 3/4” CA 4
89 64405 FORM, CHAINSHIELD 2
88 64406 TERMINAL, 1/4” RING 1
87 64407 TERMINAL, 5/16” RING 1
86 64408 WIRE, 12 GA BLACK 0.75
85 64409 WIRE, 12 GA. RED 0.75
84 63249 BOLT, 5/16” X 2 1/2” HH 1
83 64410 ADAPTER, ENGINE 1
82 64063 ROLLER, POLY 2
81 64062 SHAFT, IDLER 1
80 63586 BOLT, 1/4” X 1” HH 1
BASE LINE PV SERIES
ITEM PART NUMBER DESCRIPTION QTY
7 64417 PV SHIPPING CARTON 1
44 62768 DECAL, GASOLINE ONLY 1
51 63880 OIL, MOTOR SEE ENGINE MANUAL
65 62643 DECAL, FUEL SHUT OFF 1
72 64412 P, SPINNER PV INT. 1
74 00108-760-01 INSTR. MANUAL 1
ITEMS NOT SHOWN
00108-760-01-REV-B
Page 37
OCTOBER, 2013
