PV SERIES
INSTALLATION AND INSTRUCTIONAL MANUAL
PV SERIES
ITEM PART NUMBER DESCRIPTION QTY
27 20305 LOCKNUT, 3/8” NYLON 2
26 63294 FORM, FEEDGATE HANDLE 1
64388 FORM, FEEDGATE, HANDLE S3
25 00108-760-01 P, INSTR. MANUAL PV 1
24 62657 BOLT, 3/8” X 4” CA 4
22 SEE PARTS TABLE CHAINSHIELD, PV 2
21 62408 NUT, 1/2” HEX JAM 4
62336 NUT, 1/2” HEX JAM SS
20 62304 WELD, TAKEUP BOLT 2
19 62037 COUPLING, SHAFT 1
18 20353 FLATWASHER, 3/8” 10
22230 FLATWASHER 3/8” SS
17 20049 BOLT, 3/8” X 1” 7
62697 BOLT, 3/8” X 1” SS
16 62202 BUSHING 4
62339 BUSHING SS
15 62201 PLATE, MOTOR MTG. 1
62386 PLATE, MOTOR MTG. S3
64389 PLATE, MOTOR MTGT. S2
14 60324 MOTOR, HYDRAULIC 1
13 62281 WELD, FEEDGATE 1
62282 WELD, FEEDGATE, S3
63822 WELD, FEEDGATE, S2
12 61169 KNOB, HAND 1
11 64063 ROLLER, POLY 2
10 64062 SHAFT, IDLER 1
9 62611 NUT, 3/8” FLANGE 16
62743 NUT, 3/8” FLANGE SS
8 20327 LOCKWASHER, 3/8” 4
63206 LOCKWASHER, 3/8” SS
7 20066 BOLT, 3/8” X 1 1/4” 5
62695 BOLT, 3/8” X 1 1/4” SS
6 20329 LOCKWASHER, 1/2” 4
62270 LOCKWASHER, 1/2” SS
5 62617 BOLT, 1/2” X 3/4” 4
62750 BOLT, 1/2” 3/4” SS
4
SEE PARTS TABLE WELD, DRAG CHAIN 1
3 63264 FORM, GUARD, CONVEYOR, PV
2 63117 SUB ASSEMBLY, GEARBOX 1
1
SEE PARTS TABLE WELD, HOPPER 1
HYDRAULIC PV MODEL
