INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
ITEM PART NUMBER DESCRIPTION QTY
60 64064 IDLER COVER 2
59 64164 COVER, FEEDGATE HANDLE 1
58 62691 PIN, COTTER SS 1
57 63175 BOLT, 5/16” X 1” CA SS 4
56 62641 NUT, 5/16” FLANGE SS 18
55 62746 BOLT, 3/8” X 3/4” CA SS 1
54 62615 BOLT, 3/8” X 1 1/4” CA 1
62813 BOLT, 3/8” X 1 1/4” CA SS
53 63843 A, LIFT REAR FORKLIFT 1
51 61201 KEY, WOODRUFF 1
50 62628 LOCKNUT, 5/16” VINYL 1
49 63008 BOLT, 5/16” X 2” 1
48 SEE PARTS TABLE P, ASSY, SPINNER HYD. 1
47 63409 FLATWASHER, 3/8” SS 2
46 62007 DECAL, CAUTION 1
45 62611 BOLT, 3/8” X 1” CA 4
64447 BOLT, 3/8” X 1” CA SS
44 63179 ASSY, IDLER 1
43 SEE PARTS TABLE WELD, INV VEE 1
42 SEE PARTS TABLE WELD, SCREEN 1
41 62354 WIPER, CHAIN 1
40 62715 GROMMET, MTG. 1
39 62714 LAMP, STOP 1
38 64390 WELD, STOP LAMP BRACKET 1
64391 WELD, STOP LAMP BRACKET S3
64392 WELD, STOP LAMP BRACKET S2
37 62364 CABLE, LIGHT POWER 1
36 64393 GUARD, SHAFT 1
64394 GUARD, SHAFT S3
64395 GUARD, SHAFT S2
35 62640 BOLT, 5/16” X 3/4” CA SS 16
34 SEE PARTS TABLE FORM, FLOOR PV 1
33 62572 DECAL, MOTOR 1
32 62009 DECAL, DANGER 3
31 63295 DECAL, SERIAL NUMBER (MEYER) 1
63156 DECAL, LOGO, MEYER
29 61174 PIN, CONNECTOR W/ COTTER PIN 2
28 62270 BAR, PIVOT 1
63817 BAR, PIVOT SS
HYDRAULIC PV MODEL
30
