Meyer PV Series - Page 64

INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
TM
MATERIAL:
SCALE
TITLE
DRAWING SIZE
D
DRAWING No:
LINDENWOOD ILLINOIS
WHERE USED
CADD FILENAME:
REF. DRAWING
DR BY
APPV BY
DATE
APPVBYDATEPIF#
REV
REVISION
NOTED)
(EXCEPT AS
DO NOT SCALE DRAWING
DATE
*********************
ProE Drawing
This drawing was
created in ProE.
The orginial drawing
should only be
edited in ProE.
*********************
8.0 MIN
20.0 MAX
1.000
1.000
4.000
5.000
1.000
1.000
.500
1.000
1.000
00002-533-13
DETAIL, ASSEMBLY
ELECT DUAL MOTOR PV
SHEET 1 OF 2
SEE TABLE
PV
S:\00002\ 00002-533-13
D0000253312
0.100
JKG 8/31/2010
JKG 8/31/2010
TABD
A
10-0154
04046-020-11 WAS 04046-020-03
9/10
JG JG
PART WEIGHT
ITEM PART NUMBER DESCRIPTION QTY
1 00115-156-XX WELD, HOPPER 1 2 00118-337-01 SUB-Y, GEARBOX 1 3 04003-033-XX BOLT, 3/8" X 1 1/4" CA 1 4 00119-590-01 CONVEYOR GUARD 1 5 04150-050-00 MOTOR, ELECTRIC 1 6 04043-XXX-00 WELD, DRAG CHAIN 1 7 04003-005-XX BOLT, 1/2 X 3/4" HH 4 8 04004-001-XX LOCKWASHER, 1/2" 4 9 04046-020-11 CHAIN, ROLLER 1
10 04003-003-XX BOLT, 3/8 X 1 1/4" HH 5 11 04004-001-XX LOCKWASHER, 3/8" 4 12 04003-806-XX NUT, 3/8" FLANGE 22 13 00122-360-XX WELD, ADAPTER 1 14 00123-208-00 P. ELECTRIC CONTROL 1 15 04003-806-XX NUT, 5/16" FLANGE 18
16 04624-001-01 KNOB, HAND 1 17 00123-551-XX WELD, FEEDGATE 1 18 04003-003-XX BOLT, 3/8" X 1" HH 17 19 04004-002-XX FLATWASHER, 3/8" 5 20 00115-124-00 WELD, TAKE UP BOLT 2 21 04003-802-XX NUT, HEX JAM 4 22 SEE B/M FORM, CHAIN SHIELD 2 23 04553-008-XX SKID, SHIPPING 1 24 04003-033-XX BOLT, 3/8 X 4 CA SS 4 25 00118-312-XX FORM, FEEDGATE HANDLE 1 26 04003-804-XX LOCKNUT, 3/8" VINYL 2 27 00101-636-XX BAR, PIVOT 1 28 04045-022-00 PIN, CONNECTOR W/COTTER 2 29 00123-443-XX WELD, MOTOR COVER 1 30 00122-369-00 ROLLER, POLY 2 31 SEE B/M DECAL, SERIAL NUMBER 1
32 04049-182-00 DECAL, DANGER 3 33 04041-121-00 SPROCKET, 40B-60 X 1" BORE 1 34 04041-130-00 SPROCKET, 40B-11 X 5/8" BORE 1 35 SEE B/M FORM, CONVEYOR FLOOR 1
36 04111-053-00 CAP, IDLER 2 37 04003-032-06 BOLT, 5/16" X 3/4" CA SS
SEE B/M
38 04003-806-XX NUT, 5/16" FLANGE 4 39 04031-009-00 KEY, 3/16" 1 40 04605-155-00 CABLE, LIGHT POWER 1 41 04605-153-00 LAMP, STOP 1 42 04076-100-00 WIPER, CHAIN 1 43 00123-306-XX SCREEN, 5/16" WIRE 1 44 00119-891-00 WELD, INVERTED VEE 1 45 04003-032-04 BOLT, 5/16" X 1 CA SS 4 46 00122-366-00 SHAFT, IDLER 1 47 04049-045-00 DECAL, CAUTION 1 48 04003-033-12 BOLT, 3/8" X 3/4" CA SS 1 49 04010-016-01 PIN, 1/8" X 1" COTTER SS 1 50 04605-154-00 GROMMET, MTG 1 51 04111-052-00 COVER, FEEDGATE HANDLE 1 52 04009-001-01 KEY, WOODRUFF 1 53 00123-456-XX Y, SPINNER SU PV 1 54 04607-024-00 CLAMP, 1/2" CUSHIONED 9 55 04003-001-11 BOLT, 1/4" X 3/4" HH 9 56 04003-806-XX NUT, 1/4" FLANGE 13
ITEM PART NUMBER DESCRIPTION QTY
57 04003-003-63 BOLT, 3/8" X 3 1/2" HH SS 1 58 04049-XXX-XX DECAL, BRAND 3 59 SEE B/M P, INSTR. MANUAL 1 60 00123-441-XX FORM, SPROCKET GUARD 1 61 00122-181-01 A, REAR FORKLIFT PV 1 62 00123-442-XX FORM, REAR PLATE 1 63 04003-005-XX BOLT, 1/2" X 1 1/4" HH 2 64 04003-804-XX LOCKNUT, 1/2" VINYL 2 65 00119-329-02 ROD, SPINNER MOUNT SS 1 66 04011-001-04 KEEPER, HAIRPIN SS 1 67 04003-032-XX BOLT, 5/16" X 1" CA 4 68 04525-012-XX PAINT, POWDER
SEE B/M
69 04003-031-XX BOLT, 1/4" X 1" CA 4 70 04076-219-00 EXTENSION, FEEDGATE 1
DETAIL, IDLER ASSEMBLY
SCALE .250
36
46
30
20
21
15 37
DETAIL, FEEDGATE HANDLE ASSEMBLY SCALE .125
DETAIL, CHAIN TENSION
SCALE .250
BOTH SIDES OF CHAIN TAKEUP MUST BE ADJUSTED EVENLY
SEE CHAIN TENSION DETAIL
WIPER MUST BE ADJUSTED TO ADEQUATELY CLEAN DRAG CHAIN
EA. SIDE
(8) PLACES
ITEMS NOT SHOWN
P, INSTR. MANUAL PAINT, POWDER
59
68
15 44 45
22
15 37
6 28
10 12 19 42
35
32
58
DECALS TO BE CENTERED ON BOTH SIDES OF ITEM #1
5
38 67
11 18
13
19 57
34 39
9
33 52
31
32
47
1
2
7 8
10 12
17
19 49
27
3 26
10 12 26
16 19 48
25 51
ZERK IN BEARING TO AIM FORWARD AND UPWARD
58
56 69 70
ISO VIEW
SCALE 0.088
12 23 24
65 66
63 64
43
54 55 56
53
61
POINT WHERE CHAIN CONTACTS FLANGE ON LONGITUDINAL
A
HYDRAULIC PV MODEL
00108-760-01-REV-B
Page 64
OCTOBER, 2013
