TM
MATERIAL:
SCALE
TITLE
DRAWING SIZE
D
DRAWING No:
LINDENWOOD ILLINOIS
WHERE USED
CADD FILENAME:
REF. DRAWING
DR BY
APPV BY
DATE
APPVBYDATEPIF#
REV
REVISION
NOTED)
(EXCEPT AS
DO NOT SCALE DRAWING
DATE
*********************
ProE Drawing
This drawing was
created in ProE.
The orginial drawing
should only be
edited in ProE.
*********************
00002-533-13
DETAIL, ASSEMBLY
ELECT DUAL MOTOR PV
SHEET 2 OF 2
SEE TABLE ON SHEET 1
PV
S:\00002\
00002-533-13
D0000253312
0.100
JKG 8/31/2010
JKG 8/31/2010
TABD
A
10-0154
SEE SHEET 1
9/10
JG JG
PART WEIGHT
DETAIL, COVERS ASSEMBLY
SCALE .250
1. REMOVE COVER FROM ITEM #5.
2. INSTALL HARNESS "C" FROM ITEM #14 AS SHOWN.
3. CORDGRIP IS SUPPLIED WITH ITEM #14.
4. CONNECT RED WIRE FROM ITEM #14 TO THE BLACK
TERMINAL OF ITEM #5 AND THE BLACK WIRE FROM
ITEM #14 TO THE RED TERMINAL OF ITEM #5.
5. REPLACE COVER ON ITEM #5
WIRING INSTRUCTIONS
MOTOR
CONVEYOR
MOTOR
CONVEYOR
5
54 55 56
14
RED (+)
BLACK (-)
BLACK WIRE
RED WIRE
DETAIL, MOTOR WIRING
SCALE .250
