Circuit Component Index
Part Number Value/Description Step No. MFJ Part No.
C1 Air-variable, tuning 4-7 204-5050
C2 .1 uF 2-17 200-2017
C3 47 pF 1.9 205-0021
C4 .1 uF 1-7 200-2017
C5 5-30 pF trimmer 1-10 204-0013
C6 33 pF 2-7 200-2016
C7 .01 uF 2-2 200-2015
C8 .01 uF 2-13 200-2015
C9 .0033 polystyrene 3-11 201-0008
C10 .1 uF 3-13 200-2017
C11 .1 uF 3-10 200-2017
C12 22 uF electrolytic 3-5 203-0013
C13 100 uF electrolytic 3-3 203-0015
C14 10 uF electrolytic 3-4 203-0012
C15 .1 uF 3-9 200-2017
C16 75 pF 2-20 200-1011
C17 .0033 polystyrene 2-12 201-0008
C18 1 uF electrolytic 2-3 203-0006
C19 470 uF electrolytic 3-2 203-0004
C21 .01 uF 2-15 200-2015
C28 .01 uF 2-16 200-2015
CR1 LED 3-19 320-0001
IC1 LM386 audio amp 3-1, 3-20 311-0386
L1 10 uH 1-2 401-0102
L2 3.3 uH 1-3 401-0045
L3 1 uH 1-4 401-0037
L4 .47 uH 1-5 401-0015
L5 T-52-2 toroid, 8T 4-10 403-1003
Q1 J310 FET 2-8 305-6310
Q2 J310 FET 2-9 305-6310
Q3 J310 FET 2-10 305-6310
R1 10K pot, regeneration 4-6 162-4100-1
R2 250 ohm pot, volume 4-5 162-2250-1
R3 10K 2-4 100-4100
R4 10K 1-6 100-4100
R5 10K 2-1 100-4100
R6 1K 2-5 100-3100
R7 1M 2-11 100-6100
R8 10K 2-14 100-4100
R9 1K 3-12 100-3100
R11 22 ohms 3-7 100-1220
R12 15 ohms 3-8 100-1150
R13 2.2K 1-8 100-3220
R17 10 ohms 2-6 100-1100
R19 10K timmer, RF gain 2-19 130-4100
R20 100K trimmer, regeneration 2-18 130-5100
J1 Antenna connector 6-14 06-0003
J2 Stereo 1/8" jack 4-2 601-4010
J3 Stereo 1/8" jack 4-3 601-4010
SW1 5-position rotary switch 4-8 500-0024
SW2 DC on-off push-button switch 4-4 504-0022
