As you change VFO frequency, the display will track any change in loss in real time (losses
normally increase with frequency). Remember, Loss mode is only accurate for 50-Ohm cable
or 50-Ohm devices, and these must be unterminated at the far end.
4.4 Measure Capacitance (pF): This function measures the reactance of an unknown device
in Ohms (X) at a given test frequency and computes the component's capacitance value in pF.
To measure capacitance:
[ ] Turn on the analyzer and allow it to boot to default mode (R&X).
[ ] Press Mode twice to access Capacitance and wait for the working screen.
[ ] Adjust the Frequency switches and Tune control to the desired test frequency (MHz).
[ ] Using the shortest leads possible*, connect the capacitor to the Antenna jack.
*Alternatively, use the same lead length used in the actual circuit to incorporate stray lead
inductance in your measurement.
[ ] Read Reactance (Xc) in Ohms on top line and Capacitance in pF on the lower line:
[ ] Also, read Reactance (Xc) in Ohms on the analog Impedance meter:
Ohms
40
50
70 100
400
0
10
20
The measurement range for Reactance is 7-650 Ohms. Outside that range, the analyzer will
display one of the following error messages:
Too low to measure (X<7) Series-resonant (X=0) Too high to measure (Z>650):
Sign Ambiguity: In capacitance mode, the analyzer measures reactance (X) and the
operating frequency, then mathematically converts it to capacitance (pF). However, the
processor can't determine if the reactance sign is minus (-Xc). When in doubt, tune the VFO
up in frequency and see if the value of X decreases. If it decreases, the device is likely
