MFJ-976 Legal Limit Fully Balanced Antenna Tuner Instruction Manual
12
Suggested Tuning Chart
Frequency (MHz) Antenna Inductance Transmitter
Load(Ω)
1.8 1 46 2 25
1.8 1 48 0 50
1.8 6.5 17 0 800
2.0 0 58 2.5 25
2.0 0 63 0 50
2.0 6 35 0 800
3.5 0 95 2 25
3.5 1 95 0 50
3.5 0 79 1.5 800
3.75 0 97 1 25
3.75 1 97 0 50
3.75 0 80 2 800
4.0 1 100 0 25
4.0 2 99 0 25
4.0 0 84 2 50
5.34 2 105 0 800
7.15 2 112 0 25
7.15 3 110 0 50
7.15 0 97 6 800
10.1 4.5 116 0 25
10.1 4.5 114 0 50
10.1 8 103 7 800
14.2 6.5 117 0 25
14.2 6 114 0 50
14.2 7 113 0 800
18.1 7.5 117 0 25
18.1 7 109 0 50
18.1 9 111 0 800
21.2 8 114 0 25
21.2 8 116 6 50
21.2 0 114 9 800
24.9 8.5 119 6 25
24.9 8 117 7.5 50
24.9 0 115 9 800
28.5 9 121 8 25
28.5 8 119 9 50
28.5 4 117 9 800
