Control CS 320 / Rev.B 1.01 – 51
Display Meaning Condition
SKS 4 /
SAFE. 4
(optionally)
Closing edge protective device 4
(8.2kΩorphoto-sensor)
Radio transmission system channel 2
OPEN or CLOSE direction
Display dependent on MOD selected at
parameter SKS 4.
SKS 4 with MOD 2-3
SAFE. 4 with MOD 4
ON: System is closed.
OFF: System is interrupted (fault).
—: Not activated.
IMPULS Command button / input IMPULS
(X3 / 7+8)
ON: Button is actuated / input is active.
OFF: Button is not actuated / input is not active.
TIMER Week timer (pluggable) ON: Timer is active.
OFF: Timer is not active.
LIGHTBARR. Light barrier 1
(X4 / 1-4)
ON: Light barrier signal is OK.
OFF: Light beam interrupted or light barrier defective.
LIGHTBARR.2 Light barrier 2
Connection at input 1
(X4 / 9+10)
ON: Light barrier signal is OK.
OFF: Light beam interrupted or light barrier defective.
SAFETY CIRC. Safety circuit 1
Emergency stop systems of door system
ON: Safety circuit is closed.
OFF: Safety circuit is interrupted.
STOP Command button STOP (cover keypad) ON: Button is not actuated.
OFF: Button is actuated.
ROT FIELD Shows the currently set rolling direction
of the drive
RIGHT: Settingforarightrotatingeld.
LEFT: Settingforaleftrotatingeld.
CYCLE Door cycle counter Display of the door cycles that have run through:
1 x open + 1 x CLOSE = 1 cycle
Counting only takes place when the end switch-off points have each been reached.
SERVICE Service alarm function
Setting via parameter SERVICE and
PIN no. 2
OFF: Service display not active.
0 – 99999: Service display is active.
Display of the remaining door cycles up to the service message.
AWG Position information of the absolute
value encoder
Display of the currently transferred value.
C.STOP HALT/STOPcounter Shows how often the door was stopped. Either through activation of a safety device,
incaseofdirectdirectionreversalbyaruncommandorbyadirectSTOP/HALT
command.
C.OPENED Counter for top limit position Shows how often the top limit position was approached.
C.O.BTN Counter for OPEN commands Number of all incoming OPEN commands through command devices, sensors and
safety devices (e. g. light barrier).
