MHS Boilers Strata 2 - Wiring & Component Layout (Multiple Boilers)

23
STRATA2
5.7.3 connection diagrams
suggested wiring and component layout
for multiple Strata 2 120 installations up to 960kW
Outside Air Sensor
230 Perm Supply
With Local Isolators
RVA 47 RVA 47 RVA 47 RVA 47 RVA 47 RVA 47 RVA 47
H1 Remote Enable (Volt Fee)/or 0-10 volt
PPS
HWS Sensor
System Flow Sensor
Boiler Return Sensor
LPB
Safety Interlocks
Note: PPS & LPB cables must be screened
