Micanan PRO-GH - Table of Contents; Options

2
TABLE OF CONTENTS PAGE:
VERIFICATION OF OPERATOR AND HARDWARE __________________________________ 3
SPECIFICATIONS ______________________________________________________________ 4
SAFETY INSTRUCTIONS ________________________________________________________ 5
INSTALLATION________________________________________________________________ 6
ELECTRICAL CONNECTIONS AND SETTINGS_______________________________________ 9
LIMIT SWITCH ADJUSTMENT ___________________________________________________ 23
MICANAN PHOTOBEAM INSTALLATION INSTRUCTIONS____________________________ 24
CLUTCH ADJUSTMENT_________________________________________________________ 27
FIRE RELEASE INSTALLATION___________________________________________________ 28
BRAKE ADJUSTMENT__________________________________________________________ 29
EMERGENCY MANUAL OPERATION _____________________________________________ 30
OPERATOR MAINTENANCE ____________________________________________________ 31
MECHANICAL DRAWINGS AND PARTS LISTS _____________________________________ 32
ELECTRICAL DIAGRAMS _______________________________________________________ 36
WARRANTY ________________________________________________________________ 45
OPTIONS
MP00046
#60, #80 Drive Chain and Sprockets
MW00024
Chain Spreader 1” – 1”
MW00025
Chain Spreader 1” – 1-1/4”
PRO-_W
Waterproof modification
PRO-_4X
Corrosion proof modification
PRO-_X
Explosion proof modification
MP00007 *
115 Volt control circuit
MK00061 **
1.5 sec time delay on reverse
MP00001 **
Timer to Close
PRO-PL
Separate control panel
MP00038
Fire release mechanism
MP00037
Hand Crank
9999999
Pusher Springs
MP00069-74
Auxiliary trolley c/w track & #41 chain
MP00112-118
Dual auxiliary trolley c/w track & #41 chain
MX00001
Floor Level disconnect in lieu of chain keeper
MW00050,52
In-Line Torque Clutch
* Not available for logic board controls
** Standard feature with logic board controls
WARNING
DO NOT CONNECT TO ELECTRICAL
POWER DURING INSTALLATION
OR SERVICING OF OPERATOR
