Micatrone MF-PFTT - Parameter Groups Overview

Par.no: Parameter Range Value
Internals
0 Prog ver 0.00...9.99
Current values
100 dP -32768...32767
101 Flow -32768...32767
102 PI2 0.00...100.00
103 PI2 CSP -32768...32767
109 Temp -3276,8...3276,7
110 Purging OFF
PRE
CLEAN
POST
PAUSE
TEST
System settings
4 Display dP
FLOW
dP+FLOW
dP+PI2
FLOW+PI2
dP+TEMP
FLW+TEMP
5 Damping[s] 0...9
(hidden) Access code 0...9999
Outputs
19 Output 1 dP
FLOW
PI2
TEMP
CLEAN
20 Signal 1 0..10V
2..10V
0..20mA
4..20mA
21 Output 2 dP
FLOW
PI2
TEMP
CLEAN
22 Signal 2 0..10V
2..10V
0..20mA
4..20mA
Pressure
23 MinCal[Pa] -32768...32767
24 MaxCal[Pa] -32768...32767
25 Unit dP Pa
PaDec
mbar
iwc
26 Min Range -32768...32767
27 Max Range -32768...32767
28 Min Output -32768...32767
29 Max Output -32768...32767
30 Sign dP POS
NEG
Flow
31 Unit flow L/s
m3/s
m3/h
m/s
cfm
32 Max flow 0...32767
Par.no: Parameter Range Value
33 Scale flw 0...32767
34 Set flow 0...32767
92 Compens OFF
ACTUAL
NORMAL 0
Temperature
93 Input OFF
0..10V
2..10V
0..20mA
4..20mA
Pt-100L
Pt-100H
Pt-1000L
Pt-1000H
94 Min Input -30...600
95 Max Input -30...600
PI2 Controller
35 Source OFF
dP
FLOW
36 Mode AUTO
HAND
37 Output DIRECT
REVERSE
52 Temp 1 -30...600
53 SP1 -32768...32767
54 Temp 2 -30...600
55 SP2 -32768...32767
56 SPC OFF
TEMP
39 NZ [%] 1...50
40 P-band 0...9999
41 I-time [s] 0...999
42 BZ [%] 0...100
43 I-time BZ 0...999
96 Min out 0,00...100,00
97 Max out 0,00...100,00
Purging unit
62 Mode OFF
ON
TEST
63 On Time [s] 0...99
64 Pause [s] 30...3600
Communication
47 Adress 1...247
48 Location 0...32767
49 Protocol Comli
50 BAUD 600 b
1200 b
2400 b
4800 b
9600 b
51 Protect NO
YES
2
