3
© AB MICATRONE 2009-02-12 [H:\ Apps \ Typeset \ Mima \ Mi-261gb_090212.vp]
System settings Outputs Pressure
Output 1
Signal 1
Output 2
Signal 2
dP
0..10V
Flow
Current values
Outputs
Outputs
Outputs
Outputs
AB MICATRONE
dP
48,5Pa
Temperature
PI2 controler Purging unit
Internals
Scrolls start menus
in the opposite way
Press key until displayed text disappears.
(PGM)
Output %
(PGM)
(PGM)
(PGM)
(ESC)
(ESC)
Scrolls parameter group in the opposite way
Changes between the parameters
according to the parameter list.
Opens parameter group and allows the
parameters to be selected.
Programming position for Unit/Value (Flashes).
Programming of new value. Parameter Unit/Value is flashing.
When programming a number value, each digit is
programmed seperately, until all digits have stopped flashing.
Selection of Unit/Value.
Leaves parameters and returns to Parameter group.
Leaves the parameter group and returns to startmenu.
Always note the programmed data beside the parameter
in the programming protocol for future documentation
PI2
4..20mA
Flow/dP
Auto
%
dP
PI2
48,5Pa
15,9%
Flow
PI2
4,80m3/s
20,4%
Flow/dP
Hand
%
dP
Flow
4,80m3/s
48,5Pa
AB MICATRONE
Flow
4,80m3/s
