operating instructions
mpx
1900
4
10
11
2
1
8
6
13
14
3
4
5
5A
7
9
15
12A
16
12
17
1. Pressure Water Unit
2. Manual
3. Adjustable Spray Lance
4. Turbo Lance
5. Gun
5A. Gun Safety Button
6. Detergent Tank
7. Nozzle Cleaning Tool
8. High Pressure Hose
9. Wheels
10. High Pressure Hose Reel
11. Handle
12. Roller Brush
12A. Gun Adapter
13. Inlet adapter with filter
14. Garden Hose Fitting
15. Connection High Pressure
Hose
16. Lever & Holders Kit
17. Power Cord
package content
