10
The MR43 is designed for clean water suitable for irrigation. The machine is not designed for water
that includes large pieces of debris or slurry/wastewater conditions.
1. Tow the machine to the working site (off-road only).
WARNING!! Maximum speed is 7 MPH. Before towing the
machine, be sure no one is standing behind or around the
machine; make sure the gun cart is racked.
2. Face the gun cart side of the reel towards the area needing to
be irrigated. The machine direction should be as straight
as possible. Set the stabilizer.
3. Lower the gun cart.
4. Connect the water supply hose to the water inlet connection
on the machine.
NOTE: Before connecting the supply hose to the machine, ush
out hose or check to be sure there is no foreign matter which
will block the turbine.
5. Release the backstop (anti-reverse) lever. Pull straight back and
down to release.
6.
IMPORTANT!! Make sure the gearbox lever is in the
disengaged or idle position before unwinding tube.
