3
Bottom panel
①liquid outlet ②Handle ③Power interface ④Network cable port ⑤Control board ⑥SN
⑦liquid inlet
The single-phase liquid-cooled miner adopts the liquid circulation flow method of bottom-in and
top-out for heat dissipation. Its control panel, network cable interface, and power line interface
are all on the upper panel of the miner, which is convenient for maintenance.
2.Product parameters
Dimensions (Height X
Width X Depth)
Top panel: black
Shell: gray
Net weight: ：16kg
Weight with packaging materials:17kg
Working temperature (water intake):
20℃~45℃@normal mode; 20℃~40℃@high
performance mode;
Inlet temperature control accuracy ±2°C
Storage and transportation temperature: -
40~70℃;
Rated flow: ≥25L/min
Flow control accuracy ±10%
Remarks: 24L/min corresponds to a temperature
difference between the inlet and outlet liquids
close to 7℃ @normal mode, 10℃@high
performance mode;
insulating liquid
（
Shell S3X
）
Remarks: See Part 4 for liquid performance and
safety requirements.
Storage humidity: 5%RH~95%RH (non-
condensing)
Long-term storage humidity: 30%RH~69%RH (no
condensation)
Remarks: The above liquid flow parameters are based on Shell S3X as the liquid medium. If
