Operation
© 2006 Microchip Technology Inc. DS51616A-page 11
FIGURE 2-2: STANDARD EMULATOR SYSTEM – DEVICE WITH
ON-BOARD ICE CIRCUITRY
FIGURE 2-3: STANDARD EMULATOR SYSTEM – ICE DEVICE
Emulator Pod
Target Board
Target Device
ACTIVE
STATUS
RESETFUNCTION
Standard
Driver Board
Emulator Pod
Target Board
Transition Socket
Standard
Driver Board
ACTIVE
STATUS
RESETFUNCTION
Device-ICE
Standard Header
