MPLAB
®
REAL ICE
™
In-Circuit Emulator User’s Guide
DS51616A-page 26 © 2006 Microchip Technology Inc.
4.8.2 Configuration Tab
Set up firmware options.
• Check “Auto Download Latest Firmware” (Recommended.)
•Click Manual Download to manually select a firmware file to download to the
target device.
4.8.3 Instrumented Trace Tab
Set the size of the trace buffer.
For more on tracing, see Chapter 5. “Using the Emulator as a Debugger”.
Note: There is currently a 256k trace line maximum.
