Page 26 MSI-P602 User Manual
GPS Antenna
Active with 5m (16.5 ft) cable
Model Compact Magnetic Mount
Digital I/O Port
4 Input TTL level (Inverted)
4 Output TTL level (Inverted)
Serial Ports
Primary TSIP bi-directional
(jumper selectable as COM1, COM3 or offset)
Secondary NMEA 0183 Output
RTCM SC-104 V2.1 Input
(jumper selectable as COM2, COM4 or offset)
Interrupts
Sources 1 PPS, primary and secondary UARTs using tri-
state drivers
IRQs IRQ3 thru IRQ7 and IRQ9
1KOhm Pulldowns 3 wire-wrap selectable
Option Jumpers .025" square posts, 0.1" grid
Digital I/O Connector 3M 30316-5002
Electrical & Environmental
+5V @ 70 mA typical, continuous mode
+5V @ 45 mA typical, power save mode
-40° to 80° C
