V. SPECIFICATIONS
PC/104 16-bit, stackthrough
GPS Receiver
Frequency L1, 1575.42 MHz
C/A Code
Channels 12, continuous tracking
GPS Accuracy
Horizontal < 5 meters (50%),
< 8 meters (90%)
Altitude < 10 meters (50%),
< 16 meters (90%)
Velocity 0.06 meters/sec
PPS (static) +/- 50 nanoseconds
GPS Acquisition Rate
Autonomous Operation in Standard Sensitivity Mode
Re-acquisition < 2 seconds (90%)
Hot Start < 10 seconds (50%),
< 13 seconds (90%)
Warm Start < 38 seconds (50%),
< 42 seconds (90%)
Cold Start < 50 seconds (50%),
< 84 seconds (90%)
Cold Start requires no initialization. Warm start implies last position,
time and almanac are saved by backup power. Hot start implies
ephemeris also saved.
GPS Dynamic Condition
Altitude 18,000 m (60,000 ft.) max
Velocity 515 m/sec (1000 knots) max
Either limit may be exceeded, but not both.
GPS Protocols
TSIP
TAIP
NMEA 0183 v3.0 GGA, VTG, GLL, ZDA, GSA,
GSV and RMC
RTCM SC-104
Page 25 MSI-P602 User Manual
