17
DRAWING NO. PART NO. DESCRIPTION
1
...................... S2009 ..................................... Self Tapping Screw
2...................... S2005 ..................................... ASO Cap
3...................... S2013 ..................................... ASO Cap O–Ring
4...................... S2011 ..................................... ASO Diaphragm – Large
5...................... S2007 ..................................... ASO Piston
6...................... S2006 ..................................... ASO Piston Ring
7...................... S2010 ..................................... ASO Diaphragm – Small
8...................... S2128–03M............................ Manifold Plate
9...................... S1276 ..................................... Check Valve
10...................... S1277 ..................................... Check Valve Retainer
11...................... S7028 ..................................... Sediment/Carbon Prefilter
12...................... S1229RS ................................ T.F.C. R.O. Membrane 50 gpd (189 lpd)
13...................... S3069 ..................................... Housing O–Ring
14...................... S7029–09 ............................... Housing
15...................... R7078 ..................................... Optional Water Quality Monitor Board w/Probes
16...................... PK–A6TEU4–MG ................. 1/4" Post X 3/8" Polytube Elbow
17...................... S2116–5 ................................. Drain Restrictor 50 GPD (189 lpd) Green
18...................... S2119–01NN ......................... Cover
19...................... S7025 ..................................... Activated Carbon Post Filter
20 or ................. R2112 ..................................... Optional Water Quality Monitor Indicator and Cord
20A .................. S1580 ..................................... Water Quality Test Kit
21...................... S3072 ..................................... Wrench for Housing
22...................... S1405 ..................................... 1/4"–3/8" Fitting Wrench
23...................... S1447 ..................................... Nitrate/Nitrite Test Kit
OTHER COMPONENTS AS SHOWN IN FIGURE 1, PAGE 3.
DRAWING NO. PART NO. DESCRIPTION
1
...................... S1089–08 ............................... Long Reach Air Gap Faucet w/ 3/8" Connector
2...................... S1117–01 ............................... 3/8" Drain Clamp Assembly
5...................... S1118–01 ............................... Feed Water Saddle Valve
6 or ................ C2233 .................................... Plastic Holding Tank
6A .................. C2000F .................................. Steel Holding Tank
7...................... S1037 ..................................... Holding Tank Shut–Off Valve
