Q427+ L3 Service Manual
J1400
LCD
connector
U1706
Gyro sensor
J1804
FPC
connect
J1801
SIM
connector
J1402
TP connector
J1602
MIC
J1802
Battery
connect
J1803
T-FLASH
connector
D1500
Flashlight
J1700
Key
connect
E1101
RF
connector
E1301
Wifi/BT ANT
J1500
Camera
Connector
J1800
SIM
connecto
r
