5
speed (10/100Mbps) and mode (Full/Half Duplex). If the attached
device does not support auto-negotiation or has auto-negotiation
disabled, an auto-sensing process is initiated to select the speed
and set the duplex mode to half-duplex.
Switch-to-switch Connections
In making a switch interconnection, you could use any port to
connect another switch with straight or crossover cable. As all the
ports support auto-uplink (MDI / MDI-X) function, using a
straight cable to make a switch-to-switch connection is
allowed.
Cable Selection
Refer to the following table：
Network Speed Cable Type Max. Length
10Mbps Cat. 3, 4, 5 UTP/STP 100 meters
100Mbps Cat. 5 UTP/STP 100 meters
Note: To prevent costly equipment damage and downtime, please
consider installing a surge suppression device or a UPS
(Un-interrupted Power Supply).
