Installation
Micronet SP616R Switches do not require software configuration.
Users can immediately use any of the features of this product simply
by attaching the cables and turning on the power.
Rack Mounting
The switch can be mounted in an EIA standard 19-inch rack, which
can be placed in a wiring closet with other equipment. Attach the
mounting brackets at the switch’s front panel (one on each side),
and secure them with the provided screws.
Then, use screws provided with the equipment rack to mount each
switch in the rack.
Station Connections
Connect each station to the switch by twisted-pair cable. Plug one
RJ-45 connector into a RJ-45 port of the switch, and plug the other
RJ-45 connector into the station’s network adapter. Power on the
switch and then system is ready.
It supports Auto-Negotiation function to automatically select optimal
4
