• controller in TIMER mode

the controller is in TIMER mode when a delayed cycle has been activated. The

delay time is counted down on the “MAIN” display. The lights to the sides of the

STOP

START

and buttons both blink. The TIME light located

above to MAIN display is on.

Sect. 2) Displaying the various values (temperature, step time etc..)

Different values can be displayed, depending on the status of the controller.

In STOP mode:

Normally the controller displays the temperature of the kiln in °C on the “MAIN” display,

and the “°C” light is on

Pressing the button repeatedly scrolls through the following values, always shown on

the “MAIN” display:

• the total time in the last cycle run (e.g. 04.22 for 4 hours and 22 minutes); the TIME

light is on

• the energy consumed in the running of the last cycle (e.g. 12.36 per 12.36 kWh); the

kWh light blinks

• the total energy consumed (since the last time the counter was reset by the user); the

kWh light is on

In START mode:

Normally the controller displays the temperature of the kiln in °C on the “MAIN” display,

and the “°C” light is on

Pressing the button repeatedly scrolls through the following values, always shown on

the “MAIN” display:

• the setpoint value reached (e.g. 400 indicates 400°C; the SPV light is on).

• the running time of the cycle in progress (e.g. 01.33 for 1 hour and 33 minutes); the

TIME light is on.

• the partial kWh counter, that is, the energy consumed in the running of the current

cycle (e.g. 12.36 for 12.36 kWh); the kWh light blinks

• the total kWh counter, that is, the total energy consumed in all the cycles (this can be

reset by the user); the kWh light is on

NOTE

• It is not necessary to press the button repeatedly to return to the display of the

temperature, as the controller will automatically do this after a few seconds.
