 The new cycles entered or the modifications made to the previously entered cycles in
the user cycle group are stored permanently, even when the controller is off.
 The modify cycle procedure can also be accessed when the controller is in START
mode.
 The pre-configured cycles can also be modified, using the same procedure, however
the changes are lost when another cycle is selected.
 The controller will in any case limit the number of time/setpoint pairs (steps) that can be
set per cycle to a maximum of 31
-----------------------------------------------------------------------------------------
Example
To program a cycle with the following pairs of time/setpoint values:
01:00 600°C, 00:30 600°C, 00:45 700°C
 press
Change
for half a second
 the controller prompts the time for the first time/setpoint pair (STEP no. 1)
 press to increase the value displayed or to decrease it, until the time
displayed is 01:00 (that is, 1h), flashing
 press
Enter
 the controller prompts the setpoint for the first time/setpoint pair (STEP no. 1);
 press to increase the value displayed or to decrease it, until the temperature
displayed is 600°C, flashing
 press
Enter
 the controller prompts the time for the second time/setpoint pair (STEP no. 2)
 press to increase the value displayed or to decrease it, until the time
displayed is 00:30 (that is, 30 minutes), flashing
 press
Enter
 the controller prompts the setpoint for the second time/setpoint pair (STEP no. 2)
 press to increase the value displayed or to decrease it, until the temperature
displayed is 600°C, flashing
 press
Enter
 the controller prompts the time for the third time/setpoint pair (STEP no. 3)
 press to increase the value displayed or to decrease it, until the time
displayed is 00:45, flashing
 press
Enter
 the controller prompts the setpoint for the third time/setpoint pair (STEP no. 3)
