Keys and parts
Get to know your device.
1 USB-C connector for connecting
the phone
2 Indicator light
3 USB connector for charging other
devices
4 USB connectors for USB devices
5 HDMI connector for video output
6 DisplayPort connector for video
output
7 USB-C charger connector
8 USB-C cable
The USB-C charger and USB-C cable are included in the sales package.
HDMI and DisplayPort cables are sold separately.
Some of the accessories mentioned in this user guide may be sold separately.
Warning: The plugs of this product may contain a small amount of nickel. If you are
sensitised to nickel, prolonged skin contact with the parts may cause symptoms.
© 2015 Microsoft Mobile. All rights reserved.
