Microsoft Surface Book Installation
10 1211
13
To disarm alarm: Place IR
Key onto the IR lens on the IR
dot and press the alarm but-
ton once to disarm.
Plug the devices into the
4-position alarm box.
Conrm gold LED on the IR
dot for proper installation.
This alarm system is expand-
able. Plug in the Aux box
from the “in” port on the Aux
box, into the “out” port on the
4-position alarm box boxes
contain 8 ports for security
devices. This means that with
the original 4-position power
box and the aux box, 12 ports
will be available.
9
Plug the other end of the
white cable into the “out” port
on the Alarm unit to connect
the alarm to the 4-position
power box.
