6
6. Microsoft Surface Hub will be mounted to a temporary stand comprised of 2x8 wood cross-pieces that are attached to a steel vertical frame. Using a 6mm Hex
wrench, remove the four lag bolts that secure the mounting brackets on the back of the device to the shipping container.
WARNING: Handling
To reduce risk of injury or damage to the device, two people should remain at the ends, holding the device upright once it is standing on the oor.
WARNING: Trip hazards
To avoid trip hazards, keep the assembly area clear of packing materials. Remove materials after each step.
Your Surface Hub 84” is now unpacked and ready to be lifted from the shipping crate mounting stand to the mounting system. Follow the instructions with your
mounting system to attach Surface Hub 84”.
