Lifting Surface Hub 84”
WARNING: Weight hazard
This device is very heavy. To reduce the risk of back injuries, it is required that a minimum of four people lift the device. Two assistants should lift from the end
handles to help guide the device to the proper location, ensuring that the device is kept vertical and is not allowed to tip backwards. Two additional assistants
will help to support the weight of the device.
WARNING: Ergonomic Lifting
To reduce the potential for lifting-related injuries, follow good ergonomic lifting guidelines.
Ergonomic lifting guidance
• Plan ahead
• Determine if you can lift the unit. Is it too heavy or too awkward?
• Decide if you need lifting aid.
• Check your environment for obstructions and slippery surfaces.
• Make sure the lifting team agrees on the plan.
• Lift with your legs, not your back
• Bend at your knees, keeping the back straight.
• Keep the unit close to your body.
• Center your body over the unit. Keep the feet about shoulder width apart.
• Lift straight up smoothly.
• Keep your torso straight; do not twist while lifting or after the load is lifted.
• Set the unit onto the system slowly and smoothly with a straight back; do not let go until the unit is set in place.
What’s next?
WARNING: Do Not Proceed
Do not proceed with lifting the display or attempting to mount it without rst reading and fully understanding the mounting guide provided with your
mounting system. This is needed in order to reduce the likelihood of injury or death, or product damage.
Use the mounting guide to complete the physical setup and then use the Setup Guide in your Welcome Kit to continue setting up the software for your
Surface Hub 84”.
Note: After Surface Hub 84” is mounted, be sure to keep the lifting handles so you can use them to move Surface Hub 84” to a new mounting location or if you
need service in the future.
7
Person 1
Person 2
Person 4
Person 3
