Microtec UHP-15MS - Detailed Parts Inventory

Plain Heat Press Manual
- 8 -
No.
Parts Name
Qty
1
Machine Base 1
2
2
Machine Base 2
2
3
Pillar
2
4
Rubber Foot
4
6
Base Plate
1
7
Strengthen Pillar
1
8
M6 Hexagon Socket Screw
8
9
Strengthen Base Plate
8
10
Limited Switch
4
11
Handle Setting Plate
1
12
Handle Setting Plate
1
13
Handle Spindle
1
14
Eva Handle Bar Grip
1
15
M8 Hexagon Socket Screw
2
16
Play Mat 11*8.5
4
18
Plain Mat 5*3.5
1
19
Electromagnet Cover
1
20
Handle Arm 65*43
1
21
Welding Plate
2
22
TCA1010 Bearing
8
23
Electromagnet
1
24
Handle Arm
1
25
M8 Hex Screw
1
26
38*38 Heat Platen
2
27
38*38 Heat Platen Cover
1
28
Adapter Plate Movable Spindle
1
29
Adjusting Screw Nut
1
30
Plain Mat 43*25
1
31
M16 Adjusting Screw Rod
1
32
M10 Hand Wheel
1
33
Coiler Joint
2
34
Thermal Insulation Baffle
4
35
U Shape Plate
1
36
M6 Flat Head Cross Screws
4
37
Drawer plate
2
38
Under Plate Pillar
4
39
PWB-M3
1
40
Drawer Handle
1
41
Sliding Rod
1
44
PWB-M4
1
45
Plain Mat 28*8.5
2
46
M4 Hex Screw
4
47
Under Plate38*38
4
48
Electric Box Panel
1
49
Electric Box Cover Left
1
50
Electric Box Cover Right
1
51
Joint
1
52
Power Switch
1
53
Electric Box Cover Back
1
54
Solid-state Relay
1
55
Transformer
1
56
Screw with plastic cover
4
57
GY04 controller
1
58
Drive Board
1
59
Cross Screw
4
60
Pillar Pin 5623
2
61
Handle Arm Pin 5623
2
62
M10 Screw
8
63
Piston Rod
1
64
Gas Spring
1
65
Pin
1
66
Spring Fixed End
1
67
Tension spring Hanging Rods544
2
68
Tension spring Hanging Rods543
2
69
Heat Platen 40*50
1
70
Heat Platen Cover 40*50
1
71
Under Plate 40*50
1
72
Silicon Pad 40*50
1
73
4
74
Joint Pin
2
