Trouble Shooting
No power to video
or monitor(s)
Check fuse in cigarette lighter
adaptor
Check cigarette lighter socket
is operating correctly
No power to
monitor(s) only
Check monitor(s) are switched
on
No picture & white
noise only from LCD
monitor(s)
Ensure that the Audio/Video
loom from each monitor is
correctly connected to the
Audio/Video Out sockets of
the MVAV-S Audio/Video
selector (See page 8)
No picture or sound
from monitor(s)
Ensure that the Audio/Video
loom from the monitor is
correctly connected to the
Audio/Video Out sockets of the
MVAV-S Audio/Video selector
(See page 8)
Check that the Audio/Video
loom coming from the MVAV-S
Audio/Video selector is plugged
into the Audio/Video In on the
LCD Monitor(s) (See page 9)
N.B. If you experiencing any difficulties with the Video
Cassette Player please consult the Operating
Instructions supplied.
Troubleshooting
12
