34 MDS 9810 Installation and Operation Guide MDS 05-3301A01, Rev. C
DISPLAY OPERATING STATUS
ADDR [1...65000]
Details Page 36
Network address (1-65000)
AMASK [0000 0000–FFFF
FFFF]
Details Page 36
Sets alarm mask (response). Default is FFFF
FFFF.
ASENSE [HI/LO]
Details Page 36
Changes the sense of the alarm output. Default
sense is HI.
BAUD [xxxxx abc]
Details Page 36
Display data communication parameters.
Example: BAUD 9600 8N1
BUFF [ON, OFF]
Details Page 37
Data buffering mode: ON = seamless data
OFF = fast byte throughput
CTS [0–255]
Details Page 37
CTS delay in ms (0-255 ms)
DUMP Show all settings. Use with PC-based Radio
Configuration software (P/N 03-3156A01).
DEVICE [DCE, CTS KEY]
Details Page 38
Device behavior (DCE, or CTS KEY)
HOPTIME [XSHORT, 16, 20,
25, 32, SHORT, NORMAL,
LONG]
Details Page 40
Show hop time in milliseconds (ms).
HREV Hardware revision level
MODE [M, R, R-M]
Details Page 41
Show operating mode: M = Master, R =
Remote, R-M = Remote-Master (remote oper.
on master freqs.)
OWM Owner’s message or site name
OWN Owner’s name or system name
PWR [xx–30]
Details Page 42
Forward power output setting in dBm
RSSI
Details Page 42
Received signal strength in dBm (continuously
updated). Not available at master radio unless
SETUP is enabled.
RXTOT [NONE, 0–1440]
Details Page 43
Specifies amount of time (in seconds) to wait
before issuing a time-out alarm. Default is
NONE.
SEND [n, -n, +n]
Details Page 43
Sets/displays re-send count for data packets.
Useful in areas with heavy radio interference.
SER Serial number of radio
SHOW [PORT, DC, PWR]
Details Page 45
Show active port, DC voltage or measured RF
power (dBm)
SIMPLEX [ON, OFF]
Details Page 45
Simplex/half-duplex selection
ON = Simplex, OFF = half-duplex
SKIP [NONE, 1...8]
Details Page 46
Skip a frequency operating zone
SKIPSYNC [ON/OFF]
Details Page 46
When ON, suppresses transmission of SYNC
messages in skipped zones. Default setting is
OFF.
Display parameters continued...
Table 6. Command Summary (Continued)
COMMAND DESCRIPTION
