MIDA MIDA-EVSE-PE16S - Specifications

www.midapower.com
4
SPECIFICATION
Item
Mode 2 EV Charger Cable
Model
MIDA-EVSE-PA16S , MIDA-EVSE-PE16S
Install
Portable, plug and Play
Output Current
6A ,8A ,10A ,13A ,16A Max.
(UK Max 13A)
Rated power
3.6kW Max
Input Voltage AC
110V~250V 50Hz/60Hz
Waterproof Degree
IP67
Output Detection
1.Short circuit protection
2.Over and under frequency protection
3. Over Current Protection
4.Leakage Current Protection (restart recover）
5. Over Temperature Protection
6.Overload protection (self-checking recover)
7. Ground Protection
8.Over voltage and under-voltage protection
Operating
Temperature
-25
℃
~+55
℃
Storage Temperature
-40
℃
~+80
℃
Operating Humidity
20%-85%
EV Charger Box
Dimension
200mm(L) X 93mm(W)X51.5mm(H)
Cable Length
5Meter / 7.5Meter or Custom length
Weight
2.40kg
Standard
IEC 62752 , IEC 61851
Carton Measure
42CM*42CM*8CM
