210 H D 9 6 -2 4 - CC-T P Quick Start Guide 211
Controls
100 mm motorized faders 8 + 8 + 8 + 4
Touch-sensitive rotary controls 66
Custom controls
Fully assignable rotary controls
Fully assignable backlit buttons
28 + 8
28 + 8 + 12
Headphone controls A and B, min to max
Talk Talk gain min to max
Wi-Fi
Antenna Internal dual-band
IEEE 802.11 a/b/g/n Supports a / b / g / n devices
Frequency range 2412-2462 MHz / 5.15–5.850 GHz operation dependent on region
Max output power 20 dBm (using 5 GHz range)
Bluetooth
Version 4.0 EDR and LE
Power 20 dBm
Compatibility Supports GAP, SDN, PAN, SPP, IAP, HFP 1.5, GATT, ATTR, IAP, A2DP, ACRP.
Maximum communcation range 30 m typical
Power
Switch-mode power supply 2 x auto-ranging 100-240 V (50/60 Hz)
Power consumption 2 x 650 W
Current 9 A max
Physical
Operating temperature range 5 °C to 45 °C(41°F – 113°F)
Storage temperature range -20 °C to 60 °C (-4°F – 140°F)
Dimensions(H x W x D) 352 x 1028 x 719 mm(13.9 x 40.5 x 28.3")
Weight 43.2 kg(95.0 lbs)
Connectors
AES3 sync IN 1 x 3-pin XLR
AES3 sync OUT 1 x 3-pin XLR
External (Ethernet) connector Ethercon XLR
Monitor output 2 x HDMI (1920 x 1080p 59.94Hz/60Hz 16:9 & 720 x 480p 59.94Hz/60Hz 16:9 supported)
USB 3.0 type A hub
4 x 5 V ⎓ 900 mA
USB 3.0 type A (fader port expansion)
4 x 5 V ⎓ 900 mA
USB 2.0 type A (front surface data)
1 x 5 V ⎓ 500 mA
Diagnostics Port Serial port
MIDI In, Out and Thru 5-pin MIDI DIN sockets
Lamp 2 x 12 V DC 5 W 4-pin
IEC mains socket with power switch 2
Input / Output Characteristics
Surface input impedance 10 kΩ
Non-clip maximum input level +24 dBu
Input gain -22.5 dB to +65 dB
Phantom power (switchable per input) +48 V
Talk mic impedance 5 kΩ
Talk mic gain +15 dB to +60 dB
Talk mic max level +6 dB
Talkback impendance 20 kΩ
Talkback gain ∞0 to + 10 dB
Talkback max level +21 dBu
Surface output impedance 50 Ω
Surface output gain 0 dB
Surface output max level +21 dBu
Dynamic range 106 dB, 22 Hz to 22 kHz, unweighted
Maximum voltage gain 100 dB inputs to subgroups and masters, 106 dB inputs to aux and matrix
Crosstalk at 1 kHz -100 dB physically adjacent input channels
Crosstalk at 10 kHz -90 dB physically adjacent input channels
Fader / pan cut o at 1 kHz -100 dB
Fader / pan cut o at 10 kHz -100 dB
Headphones output impedance 10 Ω
Headphones maximum output level +21 dBu
Displays
Display screen 21" LCD high brightness 1920 x 1080 px, captive touchscreen,
up to 10 simultaneous touches
LCD info displays 41 x full colour LCD info displays, 24 mm x 24 mm (size), 240 x 240 px
Input meters (quantity 30) 12 segment -35 dBu to +20 dBu
Output meters (quantity 7) 20 segment -36 dBu to +21 dBu
Channel comp meters (quantity 28) 5 segment -24 dBu to -1 dBu
Channel gate meters (quantity 28) 5 segment -34 dBu to -5 dBu
Comp meter (quantity 1) 12 segment -23 dBu to -1 dBu
Gate meter (quantity 1) 12 segment -34 dBu to -1 dBu
Specications
