Midas M32R LIVE Quick Start Guide

18 M32R LIVE Quick Start Guide 19
7. Technical Speci cations
Processing
Input Processing Channels 32 Input Channels, 8 Aux Channels, 8 FX Return Channels
Output Processing Channels 8 / 16
16 aux buses, 6 matrices, main LRC 100
Internal E ects Engines (True Stereo / Mono) 8 / 16
Internal Show Automation (structured Cues / Snippets) 500 / 100
Internal Total Recall Scenes (incl. Preampli ers and Faders) 100
Signal Processing 40-Bit Floating Point
A/D Conversion (8-channel, 96 kHz ready) 24-Bit, 114 dB Dynamic Range, A-weighted
D/A Conversion (stereo, 96 kHz ready) 24-Bit, 120 dB Dynamic Range, A-weighted
I/O Latency (Console Input to Output) 0.8 ms
Network Latency (Stage Box In > Console > Stage Box Out) 1.1 ms
Connectors
MIDAS PRO Series Microphone Preampli er (XLR) 16
Talkback Microphone Input (XLR) 1
RCA Inputs / Outputs 2 / 2
XLR Outputs 8
Monitoring Outputs (XLR / ¼" TRS Balanced) 2/2
Aux Inputs/Outputs (¼" TRS Balanced) 6/ 6
Phones Output (¼" TRS) 1 (Stereo)
AES50 Ports (KLARK TEKNIK SuperMAC) 2
Expansion Card Interface 32 Channel Audio Input / Output
ULTRANET P-16 Connector (No Power Supplied) 1
MIDI Inputs / Outputs 1 / 1
USB Type A (Audio and Data Import / Export) 1
USB Type B, rear panel, for remote control 1
Ethernet, RJ45, rear panel, for remote control 1
Mic Input Characteristics
Design MIDAS PRO Series
THD+N (0 dB gain, 0 dBu output) < 0.01% unweighted
THD+N (+40 dB gain, 0 dBu to +20 dBu output) < 0.03% unweighted
Input Impedance (Unbalanced / Balanced) 10 kΩ / 10 kΩ
Non-Clip Maximum Input Level +23 dBu
Phantom Power (Switchable per Input) +48 V
Equivalent Input Noise @ +45 dB gain (150 Ω source) -125 dBu 22 Hz-22 kHz, unweighted
CMRR @ Unity Gain (Typical) > 70 dB
CMRR @ 40 dB Gain (Typical) > 90 dB
Input/Output Characteristics
Frequency Response @ 48 kHz Sample Rate 0 dB to -1 dB 20 Hz – 20 kHz
Dynamic Range, Analogue In to Analogue Out 106 dB 22 Hz - 22 kHz, unweighted
A/D Dynamic Range, Preampli er and Converter (Typical) 109 dB 22 Hz - 22 kHz, unweighted
D/A Dynamic Range, Converter and Output (Typical) 109 dB 22 Hz - 22 kHz, unweighted
Crosstalk Rejection @ 1 kHz, Adjacent Channels 100 dB
Output level, XLR Connectors (Nominal / Maximum) +4 dBu / +21 dBu
Output Impedance, XLR Connectors (Unbalanced / Balanced) 50 Ω / 50 Ω
Input impedance, TRS Connectors (Unbalanced / Balanced) 20 kΩ / 40 kΩ
Non-Clip Maximum Input Level, TRS Connectors +21 dBu
Output Level, TRS (Nominal / Maximum) +4 dBu / +21 dBu
Output Impedance, TRS (Unbalanced / Balanced) 50 Ω / 50 Ω
Phones Output Impedance / Maximum output Level 40 Ω / +21 dBu (Stereo)
Residual Noise Level, Out 1-16 XLR Connectors, Unity Gain -85 dBu 22 Hz-22 kHz, unweighted
Residual Noise Level, Out 1-16 XLR Connectors, Muted -88 dBu 22 Hz-22 kHz, unweighted
Residual Noise Level, TRS and Monitor out XLR Connectors -83 dBu 22 Hz-22 kHz, unweighted
DN32-LIVE USB Interface
USB 2.0 high speed, type-B (audio/MIDI interface) 1
USB input / output channels, duplex 32, 16, 8, 2
Windows DAW applications (ASIO, WASAPI and WDM audio device interface) Win 7 32/64-bit, Win10 32/64-bit
Mac OSX DAW applications (Intel CPU only, no PPC support, CoreAudio) Mac OSX 10.6.8**, 10.7.5, 10.8, 10.9, 10.10, 10.11, 10.12
DN32-LIVE SD Card Interface
SD card slots, SD/SDHC 2
SD/SDHC supported  le system FAT32
SD/SDHC card capacity, each slot 1 to 32 GB
Battery for power blackout protection (optional) CR123A Lithium cell
SD card input / output channels 32, 16, 8
Sample rates (console clock) 44.1 kHz / 48 kHz
Sample word length 32 bit PCM
File format (uncompressed multi-channel) WAV 8, 16 or 32 channels
Maximum recording time (32 ch, 44.1 kHz, 32-bit on two 32 GB SDHC media) 200 min
Typical performance recording or playback 32 channels on class 10 media, 8 or 16 channels on class 6 media
Display
Main Screen 5" TFT LCD, 800 x 480 Resolution, 262k Colours
Channel LCD Screen 128 x 64 LCD with RGB Colour Backlight
Main Meter 18 Segment (-45 dB to Clip)
Power
Switch-Mode Power Supply Auto-Ranging 100-240 VAC (50/60 Hz) ± 10%
Power Consumption 70 W
Physical
Standard Operating Temperature Range 5°C – 40°C (41°F – 104°F)
Dimensions 478 x 617 x 208 mm (18.8 x 24.3 x 8.2")
Weight 14.3 kg (31.5 lbs)
** OSX 10.6.8 Core Audio supp orts up to 16x16 channel audio

Midas M32R LIVE Specifications

General

Type	Digital Mixer
Channels	40
Buses	16
Sample Rate	48 kHz
Inputs - Mic Preamps	16 x XLR
Phantom Power	Yes
A/D Resolution	24-bit
Mic Preamps	16
Connectivity	USB
Display	5" TFT display
Outputs - Main	8
EQ Bands	4-band
Effects Types	Reverb, Delay, Chorus
Data I/O	Ultranet
USB	1 x Type A, 1 x Type B
Computer Connectivity	USB
I/O Expansion Slots	1 x Slot (32-channel audio interface, or digital networking)
MIDI I/O	In/Out
Outputs - Other	6 x 1/4" TRS, 2 x XLR (AES/EBU), 2 x 1/4" TRS (monitor)
